   >   full cutoff Glass lens

full cutoff Glass lens

  • 40W 50W 80W 100W full cutoff glass lens wall pack
  • 40W 50W 80W 100W full cutoff glass lens wall pack
  • 40W 50W 80W 100W full cutoff glass lens wall pack
  • 40W 50W 80W 100W full cutoff glass lens wall pack
40W 50W 80W 100W full cutoff glass lens wall pack40W 50W 80W 100W full cutoff glass lens wall pack40W 50W 80W 100W full cutoff glass lens wall pack40W 50W 80W 100W full cutoff glass lens wall pack

40W 50W 80W 100W full cutoff glass lens wall pack

  • Code: CWP5S/CWP5M
  • Voltage: 120-277V
  • CCT: 4000K/5000K
  • Bracket: Surface mounted
  • Product description:
  • INQUIRY

APPLICATIONS

Outdoor wall mount light Typically found on office buildings, government buildings, hospitals, college campuses, hotels, stores, and some residential settings.

SPECIFICATIONS

01. Corrosion resistant, rugged die-cast aluminum housing with powder coat paint finish.

02. The front view imported anti-UV Glass lens is 95% efficient minimizing light loss.

03. IP65 grade suitable for outdoor application.

04. All screws are stainless to make sure no rusty.

05. Direct replacement for 100 watt – 400 Watt traditional style HID wall packs

07. Glass Lens with rubber inside to make sure IP65. Easy to open fixture,

quick access to electric.

08. Wall mounted as standard, one person can finish installation, save labor cost.

09. IP65 driver and ROHS compliant, ambient operating temperature -40°C to 40°C.

10. ETL and DLC listed.

11. Button-on photocell and SPD are available as optional.

12. 120-277V/347V/480V

Item

Value

Product Code

CWP5S/ CWP5M

Mount

Surface mounted

Watt

40w/50w/80w/100w

Voltage

120-277V/347-480V

Beam Option

Full cutoff

CCT

3000K/4000K/5000K

Chip

Lumileds 3030

Driver

Weledpower (UL listed)

Lumen

40W: 4800 lumen

50W: 6000 lumen

80W: 9600 lumen

100W: 12000 lumen

Efficiency

120 LPW

Weight

40W: 3.5 Kg

50W: 3.6 Kg

80W: 4.7 Kg

100W: 4.9 Kg

Packing

40W-50W(1pcs): 7.83x6.6x 4.21in.

80W-100W(1pcs): 11.2x9.5x4.21in.

Finish

Standard: Bronze (RAL8019)

Customer Color: White or others

Installation

Surface mounted

Options

Button on photocell

SPD
